Led Advertising Signs Outdoor

45° chamfered angle design of the cabinet edge, support all kinds of large corner projects,3D screen, square screen etc. Magnetic suction installation,simple and quick maintenance for various installation environment,

Send Inquiry

Product Introduction

Introduction

With the development of the times, advertising is becoming more and more important. Traditional advertising methods can no longer meet the needs of modern society, and some novel advertising methods have emerged as the times require. Among them, led advertising signs outdoor is a very popular way of publicity. LED billboards are usually used for outdoor advertising, such as shopping malls, cinemas, and other places. It uses the latest LED technology to create a vibrant, eye-catching display. At the same time, this product is designed to be easily installed outdoors, making it ideal for any type of business or institution.

Features

The brightness of LED advertising signs outdoor is very high, reaching 6000 nits to 8500 nits, which can display very clear images and characters. Whether at night or during the day, it can automatically adjust to the best brightness. The pixel density of 24,800dots/m² and the grayscale of 13-22 bits make its color very soft and natural. With different effects, such as flashing, gradient, scrolling, etc., the LED billboard is more eye-catching, so as to achieve better propaganda effect. In addition, the LED light source has the characteristics of high efficiency and low consumption, and the average power consumption can be controlled at about 200 watts/square meter. The aluminum with good heat dissipation also keeps it at normal temperature, further reducing energy consumption.

Item	P4.7	P6.3	P9.5
Pixel Pitch	4.7625mm	6.35mm	9.525mm
LED Type	SMD1921	SMD2727	SMD2727
Module Resolution	128dots x 64dots	96dots x 48dots	64dots x 32dots
Driving Mode	1/8scan	1/6scan	1/2scan
Module Pixels	8192dots	4608dots	2048dots
Module Size	2ft * 1ft	2ft * 1ft	2ft * 1ft
Cabinet Size	2ft * 1ft	2ft * 1ft	2ft * 1ft
Cabinet Resolution	128dots x 64dots	96dots x 48dots	64dots x 32dots
Pixel Density	44,088dots/m²	24,800dots/m²	11,022dots/m²
Minimum Viewing Distance	≥4.7 m	≥6.3 m	≥9.5m
Brightness	6,000nits ~ 7,000nits	6000nits ~ 8500nits	6,000nits ~ 10,000nits
IP Grade	IP67
Refresh Rate	1,920Hz～3,840Hz( depends on IC solution)
Gray Scale	13bits～22bits( depends on IC and controller solution )
Viewing Angle	H:160° / V:160°
Maximum Power Consumption	600W/m²
Average Power Consumption	200W/m²
Input Voltage	AC110V - AC220V @ 50Hz/60Hz
Temperature	﹣20℃～45℃
Operating	10%～90%
Material	Die-casting Aluminum
Weight	3.9kg
System	Windows (Win8, Win10 etc.)
Signal Source Compatibility	DVI,HDMI1.3,DP1.2,SDI,HDMI2.0,etc.

◆ Dimension & weight

P6.3-The concise structure and light weight are designed to reduce the pressure of constructions and transportation.

The outdoor video wall cabinet depth is 64 mm only.

Cabinet weight: 3.9kg only

It is convenient for transportation and installation.

◆ Features

● Wireless: The seamless installation simplifies the structure of Led Advertising Signs Outdoor, improving its safety and stability.

●Easier and faster for assembly and disassembly.

● The outdoor led advertising board is made of two parts, the module and the frame.

●Aluminium module back shell and power supply casing accelerates heat dissipation. Therefore, the LED screen can work properly without air conditioner even when the weather temperature is as high as 55 degrees.
