outdoor electronic signs for business

outdoor electronic signs for business

Outdoor electronic signs dedicated display, the body is made of aluminum alloy, excellent waterproof performance, small wire use, high concentration of central control boxes, good stability, suitable for various outdoor environments, good comprehensive performance, high cost performance.

Product Introduction

Introduction

In the competitive business world, getting people's attention is crucial. Outdoor electronic signs for businesses attract people's attention with their bright colors, high definition, brightness, and dynamic effects. Compared with static signboards, it is easier to attract people's attention. It can display various advertising information, such as new product promotions, special promotions, marketing activities, etc., to achieve the effect of increasing sales and brand awareness. At the same time, it can also display various information such as weather forecasts, dates, news, and announcements. This makes it not just a simple advertising medium, but a multi-functional information publishing platform.


Features

Outdoor electronic signs for business have high resolution and brightness, the module pixels can reach 2304dots, and the brightness is about 6000-10000 nits, so the screen can clearly display various characters and patterns under strong sunlight, ensuring the integrity of information spread effect. At the same time, its shell is made of high-strength aluminum alloy, which has good waterproof and windproof properties, ensuring its stable operation in various environments. We have also sealed the control panel and lamp beads, and the sealing of the box is also very high so that it will not fail even after being exposed to wind and rain (the protection level reaches IP67). Its working temperature is -20°C~65°C, and the working humidity is 10%~90%


1657701781774438 (1)

Front maintenance

No complicated work steps are required, just remove

 the module covering the power box, and then the power

box can be opened for maintenance work.

Disassembly control box

Separate control box is simple in structure,

and is stable and reliable.


1657701737315823 (1)
1657701692594575dd

Fully sealed structure design

The outdoor electronic signs for business adopts IP67 design,

is suitable for various working environments:

dusty roadside, wet seashore etc.

High flatness

Aluminum alloy frame is processed by CNC, and its flatness

can be controlled within 0.5mm, which is far better

than the traditional fabricate metal cabinet.

1657700959534363 (1)

High-fidelity

It support HDR high dynamic range display,

and offers clear picture quality.


Convenient installation method

It has imple installation structure,

convenient operation method,

strong body stability.










ItemP6.67P8P10
Pixel Pitch 6.667mm8mm10mm
LED Type SMD2727SMD2727SMD2727
Module Resolution 48dots × 48dots40dots × 40dots32dots × 32dots
Driving Mode 1/4scan1/4scan1/2scan
Module Pixels 2,304dots1,600dots1,024dots
Module Size 320mm × 320mm320mm × 320mm320mm × 320mm
Cabinet Size 960mm × 960mm × 110mm960mm × 960mm × 110mm960mm × 960mm × 110mm
Cabinet Resolution 144dots × 144dots120dots × 120dots96dots × 96dots
Pixel Density 22,500 dots/15,625dots/10,000dots/
Best Viewing Distance 6.67m8m10m
Brightness 6,500nits or 10,000nits6,000nits or 9,000nits6,000nits or 10,000nits
IP Grade IP67
Refresh Rate 1,920Hz3,840Hzz(depends on IC driver solution)
Gray Scale 14bits22bits(depends on IC driver and controller solution )
Viewing Angle H:110° / V:110°
Maximum Power Consumption  800W/
Average Power Consumption265W/
Input Voltage AC220V AC110V @ 50Hz / 60Hz
Operating Temperature 20℃~65
Operating Humidity10%90%
Cabinet MaterialAluminum profile
Cabinet Weight 30kg/panel
Operating System Windows (Win7, Win10, etc.)
Signal Source Compatibility DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc.
