Digital Sign Board Outdoor
The pixel density up to 44088 dots/ ㎡ with outstanding image quality. True to content effects are created with 4800+ Hz high refresh rate, outstanding color processing and great contrast ratios.
Product Introduction
Digital sign board outdoor-LFA P4.76
Item | P4.7 | P6.3 | P9.5 |
Pixel Pitch | 4.7625mm | 6.35mm | 9.525mm |
LED Type | SMD1921 | SMD2727 | SMD2727 |
Module Resolution | 128dots x 64dots | 96dots x 48dots | 64dots x 32dots |
Driving Mode | 1/8scan | 1/6scan | 1/2scan |
Module Pixels | 8192dots | 4608dots | 2048dots |
Module Size | 2ft * 1ft | 2ft * 1ft | 2ft * 1ft |
Cabinet Size | 2ft * 1ft | 2ft * 1ft | 2ft * 1ft |
Cabinet Resolution | 128dots x 64dots | 96dots x 48dots | 64dots x 32dots |
Pixel Density | 44,088dots/m² | 24,800dots/m² | 11,022dots/m² |
Minimum Viewing Distance | ≥4.7 m | ≥6.3 m | ≥9.5m |
Brightness | 6,000nits ~ 7,000nits | 6000nits ~ 8500nits | 6,000nits ~ 10,000nits |
IP Grade | IP67 | ||
Refresh Rate | 1,920Hz～3,840Hz( depends on IC solution) | ||
Gray Scale | 13bits～22bits( depends on IC and controller solution ) | ||
Viewing Angle | H:160° / V:160° | ||
Maximum Power Consumption | 600W/m² | ||
Average Power Consumption | 200W/m² | ||
Input Voltage | AC110V - AC220V @ 50Hz/60Hz | ||
Temperature | ﹣20℃～45℃ | ||
Operating | 10%～90% | ||
Material | Die-casting Aluminum | ||
Weight | 3.9kg | ||
System | Windows (Win8, Win10 etc.) | ||
Signal Source Compatibility | DVI,HDMI1.3,DP1.2,SDI,HDMI2.0,etc. | ||
Dimension & Weight
 |  |
●Ultra-thin panel, the highest position thickness is only 64mm. | ●Ultra-light design, single panel weighs only 3.9Kg |
Features
Maintenance
●Front and rear maintenance*available.
●Faster and easier to installand disassembly.
●Magnetic suction installation,simple and quick maintenancefor various installationenvironment, improve workefficiency.
Double waterproof
●Fully water resistantpanel, IP67 protection rating.
●Suitable for any harsh environment
●Matching specialty: Waterproof box, waterproof module, waterproof power box
Video processing
●High refresh(≥1920-3840hz), high grayscale, ghost-canceling, gorgeous picture showing.
●Gold aspect ration:4:3/16:9.Customized resolution:1080p,2K,4K,8K, etc
●Die-casting aluminum cabinet,high precision, good flatness, seamless splicing.
●Special frame structure make excellent heat dissipation, quiet operation without fan.
●Lager viewing angle and smooth displaying, excellent visual effect from every angle.
●Portable use at different locations, easily suspended on truss with hanging bars.
Right Angle screen
45° chamfered angle design of the cabinet edge, support all kinds of large corner projects,3D screen, square screen etc.
 |  |
Installation type
●Modular connection of display elements
Flexible sizes available: 8’*4’/6’*3’ or Customized design, installation can be billboard , bus shelter, mobile signs , etc.
Our Case
| Time saving,labors saving and money saving | ||
 |  |  |
 |  |  |
 |  |  |
Production process
Package and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
