P8 Full Color Led Signs Outdoor
LOF outdoor display, Universal sheet metal box, strong plastic, can be freely customized, free selection of configuration, low maintenance cost, convenient installation, high environmental compatibility, strong cost performance. Outdoor RGB p10 led display module, HDR dynamic display, high gray scale, high brightness, clear and sharp picture display. According to different project requirements, it supports custom box maintenance methods, and all components can be maintained before and after. You can also see the LOF outdoor led display in many outdoor places, such as the outside message waterproof led board, led video billboard signs and so on. It IP degrees reached IP65 level of protection, edge protection against backflow through the cable port, isolation of water vapor corrosion, high degree of sealing of modules and rear doors, dust-proof, waterproof and corrosion-resistant.
Product Introduction
Products Description
Double maintenance, more secure
The box can be customized maintenance mode, more in line with the local use conditions
Hd horizon
High brightness, low gray, excellent picture, to create a perfect visual feast
Ultra wide perspective
Super wide range of viewing Angle, any Angle can be barrier-free viewing
Multi-channel power fan, power fan heat
Product Picture
Our factory
FAQ
How to help users choose the right display?
(1) Show the content of the content;
(2) Confirmation of visual distance and perspective;
(3) Requirements for the scoring debate rate;
(4) The requirements for installation environment;
(5) Cost control;
Item | P3.91 | P4.81 | P5 | P6.15 | P6.67 | P8 | P10 | P10 | P16 | P20 |
Pixel Pitch | P3.906mm | 4.807mm | 5mm | 6.154mm | 6.667mm | 8mm | 10mm | 10mm | 16mm | 20mm |
LED Type | SMD1921 | SMD1921 | SMD1921 | SMD1921 | SMD2727 | SMD2727 | SMD2727 | DIP346 | DIP346 | DIP346 |
Module Resolution | 64dots × 64dots | 52dots × 52dots | 64dots × 32dots | 52dots × 26dots | 48dots × 24dots | 40dots × 40dots | 32dots × 32dots | 32dots × 16dots | 20dots × 10dots | 16dots × 8dots |
Driving Mode | 1/16scan or 1/8scan | 1/7scan | 1/8scan | 1/7scan | 1/6scan | 1/4scan | 1/2scan | 1/4scan | static | static |
Module Pixels | 4,096dots | 2,704dots | 2,048dots | 1,352dots | 1,152dots | 1,600dots | 1,024dots | 512dots | 200dots | 128dots |
Module Size | 250mm × 250mm | 320mm × 160mm | 320mm × 320mm | 320mm × 160mm | ||||||
Cabinet Size | 1,000mm × 1,000mm | 960mm × 960mm | ||||||||
Cabinet Resolution | 256dots × 256dots | 208dots × 208dots | 192dots × 192dots | 156dots × 156dots | 144dots × 144dots | 120dots × 120dots | 96dots × 96dots | 96dots × 96dots | 60dots × 60dots | 48dots × 48dots |
Pixel Density | 65,536dots/㎡ | 43,264dots/㎡ | 40,000dots/㎡ | 26,406.25dots/㎡ | 22,500dots/㎡ | 15,625dots/㎡ | 10,000dots/㎡ | 10,000dots/㎡ | 3,906dots/㎡ | 2,500dots/㎡ |
Best Viewing Distance | ≥3.9m | ≥4.8m | ≥5m | ≥6m | ≥6.67m | ≥8m | ≥10m | ≥10m | ≥16m | ≥20m |
Brightness | 5,000nits or 6,500nits | 6,500nits | 6,000nits | 6,000nits | 6,000nits | 6,000nits | 6,000nits | 7,000nits | 7,000nits | 6,000nits |
IP Grade | IP65 | |||||||||
Refresh Rate | 1,920Hz～3,840Hz(depends on IC driver solution) | |||||||||
Gray Scale | 14bits～22bits(depends on IC driver and controller solution) | |||||||||
Viewing Angle | H:110° / V:110° | H:110° / V:55° | H:110° / V:55° | H:110° / V:55° | ||||||
Maximum Power Consumption | 750W/㎡ or 1000W/㎡ | 1000W/㎡ | 750W/㎡ | 750W/㎡ | 680W/㎡ | 800W/㎡ | 800W/㎡ | 530W/㎡ | 500W/㎡ | 500W/㎡ |
Average Power Consumption | 250W/㎡ or 330W/㎡ | 330W/㎡ | 250W/㎡ | 250W/㎡ | 220W/㎡ | 260W/㎡ | 260W/㎡ | 170W/㎡ | 160W/㎡ | 160W/㎡ |
Input Voltage | AC110V～AC220V @ 50Hz / 60Hz | |||||||||
Operating Temperature | ﹣20℃～50℃ | |||||||||
Operating Humidity | 10%～90% | |||||||||
Cabinet Material | Iron / Aluminum | |||||||||
Cabinet Weight | 45kg/㎡ or 38kg/㎡ | 45kg/㎡ or 38kg/㎡ | 45kg/㎡ or 38kg/㎡ | 45kg/㎡ or 38kg/㎡ | 45kg/㎡ or 38kg/㎡ | 45kg/㎡ or 38kg/㎡ | 45kg/㎡ or 38kg/㎡ | 65kg/㎡ or 55kg/㎡ | 65kg/㎡ or 55kg/㎡ | 65kg/㎡ or 55kg/㎡ |
Operating System | Windows (Win7, Win10, etc.) | |||||||||
Signal Source Compatibility | DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc. | |||||||||
