Outdoor Led Video Wall Rental
The heat dissipation structure is completely integrated, and the fanless operation is isolated; the cabinet operation has high strength, good specificity, high precision, and is not easy to deform.
Product Introduction
Dimensions and Weight
High precision, good strength, good flatness, using die-casting aluminum box. Lightweight and very convenient for different types of procedures. The weight is only 7.5kg and the thickness is only 85mm, which reduces the transportation cost, reduces the labor intensity of the staff, and reduces the bearing capacity of the steel structure.
● Special heat dissipation structure, excellent heat dissipation, no fan design, absolutely silent operation; the cabinet is made of cast aluminum, which has high strength, good toughness, high precision, and is not easy to deform.
●Cabinet assembly structure has positioning function; positioning + alignment hole design; and use special buckle connection; humanized handle design on both sides of the cabinet; the flatness and splicing of the whole screen, the gap is less than 0.02mm.
●High-contrast, high-gray, flicker-free video images, excellent color reproduction ability, return to nature.
●High refresh rate up to 1920Hz, reliable dynamic image performance, it has higher contrast ratio, softer picture and better stereo vision.
◆ Design details
● Maintenance ( both back and rear maintenance)
Support full maintenance before and after, realize quick disassembly and assembly in different occasions, and better installation experience.
The left and right direction of the display screen is ≥160°, and the up and down direction viewing angle is ≥120°. Even though the screen is facing direct light, there is no reflected image.
◆ Installation
The installation method is flexible and diverse, and supports stacking, hoisting, curved screen, steel frame screen and other installation methods. The installation and use are simple and fast. No matter any scene, there is always an installation method that can meet the differentiated needs of customers.
Item | P1.9 | P2.6 | P2.9 | P3.9 | P4.8 | P5.9 |
Pixel Pitch | 1.953mm | 2.604mm | 2.976mm | 3.906mm | 4.807mm | 5.952mm |
LED Type | SMD1212 | SMD1415 | SMD1415 | SMD1921 | SMD1921 | SMD2727 |
Module Resolution | 128dots × 128dots | 96dots × 96dots | 84dots × 84dots | 64dots × 64dots | 52dots × 52dots | 42dots × 42dots |
Driving Mode | 1/32scan | 1/16scan or 1/32scan | 1/14scan or 1/ 21scan | 1/16scan or 1/8scan | 1/13scan or 1/7scan | 1/7scan |
Module Pixels | 16,384dots | 9,216dots | 7,056dots | 4,096dots | 2,704dots | 1,764dots |
Module Size | 250mm × 250mm | 250mm × 250mm | 250mm × 250mm | 250mm × 250mm | 250mm × 250mm | 250mm × 250mm |
Cabinet Size | 500mm × 500mm | 500mm × 500mm | 500mm × 500mm | 500mm × 500mm | 500mm × 500mm | 500mm × 500mm |
Cabinet Resolution | 256dots × 256dots | 192dots × 192dots | 168dots × 168dots | 128dots × 128dots | 104dots × 104dots | 84dots × 84dots |
Pixel Density | 262,144dots/㎡ | 147,456dots/㎡ | 112,896dots/㎡ | 65,536dots/㎡ | 43,264dots/㎡ | 28,224dots/㎡ |
Minimum Viewing Distance | ≥1.9m | ≥2.6m | ≥2.9 m | ≥3.9 m | ≥4.8 m | ≥5.9m |
Brightness | 4,000nits | |||||
IP Grade | IP65 | |||||
Refresh Rate | 1,920Hz～3,840Hz | |||||
Gray Scale | 13bits～24bits | |||||
Viewing Angle | H:160° / V:160° | |||||
Maximum Power Consumption | 800W/㎡ | |||||
Average Power Consumption | 230W/㎡ | |||||
Input Voltage | AC110V～AC220V @ 50Hz / 60Hz | |||||
Operating Temperature | ﹣20℃～65℃ | |||||
Operating Humidity | 10%～90% | |||||
Cabinet Material | Die-casting Aluminum | |||||
Cabinet Weight | 7.5kg/panel | |||||
Operating System | Windows (Win7, Win8, etc.) | |||||
Signal Source Compatibility | DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc. | |||||
